[shortdesc]

1U Rack PDU, 15A / 120V, 8 NEMA 5-15R Outlets, Horizontal Mount, Metered for Load Monitoring

[/shortdesc]

[properties]

Brand	APC by Schneider Electric
Model	AP7800B
Product Type	NetShelter Metered Rack PDU
Form Factor	Rackmount 1U
Dimensions (H x W x D)	1.73" x 17.48" x 4.02" (44 x 444 x 102 mm)
Weight	3.81 lb (1.73 kg)
Color	Black
Number of Rack Units	1U
Mounting Mode	Rack-mounted (Horizontal, Front/Rear)
Cooling	Passive

[/properties]

[specifications]

PDU Type	Metered
Input Voltage	100 V / 120 V
Output Voltage	120 V
Input Plug Type	NEMA 5-15P
Input Frequency	50/60 Hz
Line Rated Current	12 A (Max 15 A)
Load Capacity	1440 VA
Outlets	8 × NEMA 5-15R
Communication Ports	None (local metering only)
Operating Temperature	23–113 °F (-5–45 °C)
Storage Temperature	-13–149 °F (-25–65 °C)
Operating Humidity	5–95% non-condensing
Storage Humidity	5–95% non-condensing
Operating Altitude	0–10,000 ft
Storage Altitude	0–50,000 ft
Compliance	cUL Listed, CSA, METI Denan, UL Listed, VCCI, FCC Part 15 Class A, ICES-003, UL 60950, RoHS, REACh
Warranty	2 years repair or replace

[/specifications]

[accessories]

Cord Retention Brackets	Included in the box
Installation Guide	Included in the box
Rack Mounting Brackets	Included in the box
User Manual	Included in the box
Warranty Card	Not specified

[/accesories]

[specifications]

[/specifications]

Overview

The APC AP7800B NetShelter Metered Rack PDU provides efficient power distribution in a compact 1U horizontal form factor. Designed for IT racks and network closets, it supports 15A input at 120V and offers real-time load monitoring with metering to ensure optimal energy use.

Key Features & Benefits

• Metered Monitoring: Enables precise measurement of load levels for capacity planning.
• Compact 1U Design: Fits seamlessly into rack enclosures without consuming vertical space.
• High Outlet Density: Equipped with 8 NEMA 5-15R outlets for efficient device connectivity.
• Reliable Build: Durable design with front or rear mounting flexibility.
• 11.98 ft Power Cord: Provides placement versatility in various rack setups.

Technical Deep Dive

The AP7800B utilizes a metered design that goes beyond basic power strips, giving IT managers visibility into real-time current draw. This ensures balanced load distribution and helps prevent circuit overloads.

With its 1U horizontal rack form factor, the PDU optimizes rack space and can be mounted either at the front or rear for operational convenience. The long 3.65m input cord with NEMA 5-15P plug enhances deployment flexibility.

Operating across 100–120V input and providing stable 120V output, it supports up to 1440 VA load capacity. Designed for demanding data center and networking environments, it meets UL and FCC standards for safety and compliance.

Ideal Applications

• Small to mid-size data racks and network closets
• Branch office IT infrastructure
• Server, storage, and networking equipment
• Environments requiring precise load monitoring

Frequently Asked Questions (FAQs)

Q1: How is the AP7800B installed?
A: It is a 1U horizontal rack-mounted unit and includes mounting brackets for front or rear installation.

Q2: What is its performance capability?
A: The unit supports up to 15A input with 1440 VA capacity. Actual load handling depends on connected equipment and environment.

Q3: Does it provide monitoring features?
A: Yes, it includes metering functionality to measure real-time load, assisting in capacity management and preventing overloads.
